Cat.No.: 30002
The Drop Maker is an integrated optical, mechanical and electrical device with a proprietary microfluidic chip that can rapidly produce nanolitre (<1nl) water-in-oil droplets from aqueous phase samples.
Drop Maker
Description
Overview
Specification
Video
Specification
| Items | Technical parameters | Technical advantages |
| Initial sample size | 20-50 μL | The loading volume can be flexibly adjusted to allow for more sample sizes, and need lower copy number samples mean higher sensitivity. |
| Number of sample microdroplets can be generated | 40,000-100,000 | High number of microdroplets, small separation error, large linear range. |
| Microdroplet size | Diameter approx. 90nm，volume approx. 0.5 nL | |
| Microdroplet homogeneous stability | CV<1% | Homogeneous size and good stability after amplification |
| Microdroplet preparation time | <5min/8 samples | 8 channels can be generated simultaneously or flexibly adjusted.
Can save reagent consumables |
| Microdroplet collection method | 8-Strip PCR EP Tube | Compatible with common PCR instruments for easy high-throughput amplification |
| Overall dimensions | L×W×H：385mm×334mm×365mm | |
| Weight | 19 kg | |
| Power supply | 220V，50Hz | |
| Power rating | 100VA | |
| Work environment requirements | Temperature: 10℃～30℃, Relative humidity:<70% |
